| Type of Product | Indoor Antennas |
| Impedance | 50 Ohms |
| Type | Dipole |
| Style | Blade Tilt / Swivel |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Indoor Antennas |
Impedance |
50 Ohms |
Type |
Dipole |
Style |
Blade Tilt / Swivel |
Height |
10 mm |
Length |
135.7 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-5GWWS1-SMA |
Manufacturer Part Number |
ANT-5GWWS1-SMA |
Maximum Frequency |
4.99 GHz |
VSWR |
1.4, 1.7, 1.9, 2.8, 2.9, 3, 3.1 |
Minimum Frequency |
617 MHz |
Gain (Db) |
0.4 dBi, 0.6 dBi, 0.7 dBi, 2.2 dBi, 2.4 dBi, 2.7 dBi, 3.3 dBi, 3.5 dBi, 4 dBi, 4.1 dBi |
Centre Frequency |
657.5 MHz, 750.5 MHz, 875.5 MHz, 1581 MHz, 1955 MHz, 2350 MHz, 2593 MHz, 3550 MHz, 3625 MHz, 3950 MHz, 4965 MHz |
Antenna Connector |
SMA Male |
Minimum Operating Temperature |
- 20°C |
Maximum Operating Temperature |
+ 65°C |
Series |
5GW |
RoHS Compliant |
Yes |
Product Type |
Multiprotocol Antennas |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ant-5gwws1-sma-ds&DocType=Data+Sheet&DocLang=English&DocFormat=pdf&PartCntxt=ANT-5GWWS1-SMA |
Number of Bands |
11 Band |
Width |
20.1 mm |
Termination Style |
Connector |
Mounting Style |
Panel Mount |
Power Rating |
5 W |
Protocol - Cellular, NBIoT, LTE |
2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, EBS |
Mechanical Style |
Whip |
Application |
Private Cellular Networks, IoT |
Protocol - Sub GHz |
IoT, ISM |
Protocol - WiFi - 802.11 |
LoRaWAN, Sigfox, WiFi, WLAN |
