| Type of Product | Indoor Antennas |
| Impedance | 50 Ohms |
| Type | Monopole |
| Style | Straight |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Indoor Antennas |
Impedance |
50 Ohms |
Type |
Monopole |
Style |
Straight |
Bandwidth |
200 MHz |
Length |
83.5 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-868-PW-QWUFL |
Manufacturer Part Number |
ANT-868-PW-QW-UFL |
Maximum Frequency |
950 MHz |
VSWR |
1.9 |
Minimum Frequency |
750 MHz |
Gain (Db) |
1.6 dBi |
Centre Frequency |
868 MHz |
Antenna Connector |
MHF / U.FL |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 90°C |
Series |
PW |
RoHS Compliant |
Yes |
Product Type |
IoT Antennas - LPWAN, LoRaWAN, Sigfox, NB-IoT |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ANT-868-PW-QW-xxx&DocType=Data+Sheet&DocLang=English&DocFormat=pdf&PartCntxt=ANT-868-PW-QW-UFL |
Number of Bands |
1 Band |
Termination Style |
Connector |
Mounting Style |
Direct / Permanent Mount |
Cable Type |
216 mm RF1.32 |
Protocol - Cellular, NBIoT, LTE |
Cellular (NBIoT, LTE), GSM, UMTS |
Mechanical Style |
Whip |
Application |
FirstNet/Public Safety, Sensing, Remote Monitoring, Handheld Devices |
Protocol - Sub GHz |
RFID |
Protocol - WiFi - 802.11 |
LoRaWAN, Sigfox |
