| Type of Product | Indoor Antennas |
| Impedance | 50 Ohms |
| Bandwidth | 84 MHz, 700 MHz |
| Height | 0.5 mm |
Type of Product |
Indoor Antennas |
Impedance |
50 Ohms |
Bandwidth |
84 MHz, 700 MHz |
Height |
0.5 mm |
Length |
3.2 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-L000951-01 |
Manufacturer Part Number |
L000951-01 |
Maximum Frequency |
5.85 GHz |
VSWR |
8.4027777777777785E-2 |
Minimum Frequency |
2.4 GHz |
Gain (Db) |
- 4 dB, 1.4 dBi |
Antenna Connector |
SMA-Female |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
RoHS Compliant |
Yes (By Exemption) |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Electrical Type |
Chip |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=L000951&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=L000951-01 |
Number of Bands |
2 Band |
Width |
1.6 mm |
Termination Style |
SMD/SMT |
Mounting Style |
PCB Mount |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth |
Protocol - GPS, GLONASS |
GPS |
Protocol - WiFi - 802.11 |
WiFi |
