| Type of Product | Indoor Antennas |
| Impedance | 50 Ohms |
| Type | Dipole |
| Style | Tilt/Swivel |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Indoor Antennas |
Impedance |
50 Ohms |
Type |
Dipole |
Style |
Tilt/Swivel |
Length |
195 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-5GMWP1-SMA |
Manufacturer Part Number |
ANT-5GMWP1-SMA |
Maximum Frequency |
5 GHz |
VSWR |
1.7 |
Minimum Frequency |
3.3 GHz |
Gain (Db) |
4.9 dBi |
Centre Frequency |
3.625 GHz, 3.95 GHz, 4.965 GHz |
Antenna Connector |
SMA Plug |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 65°C |
Series |
5GM |
RoHS Compliant |
Yes |
Product Type |
Cellular Antennas - GSM, LTE, 2G/3G/4G/5G |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ant5gmwp1smads&DocType=Data+Sheet&DocLang=English&DocFormat=pdf&PartCntxt=ANT5GMWP1SMA |
Number of Bands |
1 Band |
Termination Style |
Connector |
Mounting Style |
Connector |
Power Rating |
10 W |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Protocol - Cellular, NBIoT, LTE |
5G, Cellular (NBIoT, LTE), GSM |
Mechanical Style |
Whip |
Application |
Private Cellular Networks, Public Safety Networks |
Protocol - Sub GHz |
IoT |
