| Type of Product | Outdoor Antennas |
| Impedance | 50 Ohms |
| Type | Dipole |
| Style | T-Bar |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Outdoor Antennas |
Impedance |
50 Ohms |
Type |
Dipole |
Style |
T-Bar |
Bandwidth |
14 MHz |
Height |
9.2 mm |
Length |
138 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-868-MHW-SMAL |
Manufacturer Part Number |
ANT-868-MHW-SMA-L |
Maximum Frequency |
876 MHz |
VSWR |
1.9 |
Minimum Frequency |
862 MHz |
Gain (Db) |
5.4 dBi |
Centre Frequency |
868 MHz |
Antenna Connector |
SMA Male |
Minimum Operating Temperature |
- 20°C |
Maximum Operating Temperature |
+ 70°C |
Series |
MHW |
RoHS Compliant |
Yes |
Product Type |
IoT Antennas - LPWAN, LoRaWAN, Sigfox, NB-IoT |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ant-868-mhw-ccc-c-ds&DocType=Data+Sheet&DocLang=English&DocFormat=pdf&PartCntxt=ANT-868-MHW-SMA-L |
Number of Bands |
1 Band |
Width |
15.5 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Power Rating |
10 W |
Cable Type |
4.6 M RG174 |
Protocol - Cellular, NBIoT, LTE |
Cellular (NBIoT, LTE), GSM, UMTS |
Mechanical Style |
Module |
Application |
Low Power Wide Area Applications, IoT Devices, Remote Control, Monitoring, Sensing |
Protocol - Sub GHz |
RFID |
Protocol - WiFi - 802.11 |
LoRaWAN, Sigfox |
