Ships within 45 days
View
View
View
View
| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | FPC Antenna |
| Style | Flexible |
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
FPC Antenna |
Style |
Flexible |
Height |
0.15 mm |
Length |
100 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-L000836-09 |
Manufacturer Part Number |
L000836-09 |
Maximum Frequency |
5 GHz |
Minimum Frequency |
617 MHz |
Antenna Connector |
MHF4L Type Plug |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 85°C |
RoHS Compliant |
Yes |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=L000836&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=L000836-09 |
Number of Bands |
7 Band |
Width |
15 mm |
Termination Style |
Connector |
Mounting Style |
Adhesive Mount |
Power Rating |
10 W |
Cable Type |
1.13 mm |
Mechanical Style |
Rectangular |
