| Type of Product | Modules |
| Impedance | 50 Ohms |
| Height | 46.5 mm |
| Length | 200 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Modules |
Impedance |
50 Ohms |
Height |
46.5 mm |
Length |
200 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
239-L000962-01 |
Manufacturer Part Number |
L000962-01 |
Maximum Frequency |
7.125 GHz |
VSWR |
8.4027777777777785E-2 |
Minimum Frequency |
2.4 GHz |
Gain (Db) |
9.6 dBi |
Antenna Connector |
SMA-RP |
Minimum Operating Temperature |
- 50°C |
Maximum Operating Temperature |
+ 70°C |
Series |
ProSig |
IP Rating |
IP67 |
RoHS Compliant |
Yes (By Exemption) |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ANT-DS-L000962&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=L000962-01 |
Number of Bands |
3 Band |
Width |
200 mm |
Termination Style |
Connector |
Mounting Style |
Panel Mount |
Power Rating |
2 W |
Cable Type |
RG-58LL |
