| Type of Product | PCB Antennas |
| Impedance | 50 Ohms |
| Type | Embedded Monopole |
| Style | Stubby |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Antennas |
Impedance |
50 Ohms |
Type |
Embedded Monopole |
Style |
Stubby |
Bandwidth |
50 MHz |
Length |
17.6 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
712-ANT-2.4-JJB-ST |
Manufacturer Part Number |
ANT-2.4-JJB-ST |
Maximum Frequency |
2.48 GHz |
VSWR |
2 |
Minimum Frequency |
2.39 GHz |
Gain (Db) |
- 1.5 dBi |
Centre Frequency |
2.45 GHz |
Minimum Operating Temperature |
- 40°C |
Maximum Operating Temperature |
+ 90°C |
Series |
JJB |
RoHS Compliant |
Yes |
Product Type |
2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=L9000080-01&DocType=Data+Sheet&DocLang=English&DocFormat=pdf&PartCntxt=L9000080-01 |
Number of Bands |
1 Band |
Termination Style |
Through Hole |
Mounting Style |
PCB Mount |
Protocol - ANT |
802.15.4 (ANT, Thread, Zigbee), 802.16 |
Protocol - Bluetooth BLE - 802.15.1 |
Bluetooth, BLE |
Mechanical Style |
Whip |
Application |
Bluetooth, WiFi, Zigbee, Thread |
Protocol - Sub GHz |
ISM |
Protocol - WiFi - 802.11 |
WiFi |
