| Type of Product | Modules |
| Impedance | 50 Ohms |
| Country of Origin | India |
| Name of Manufacturer/Packer/Importer | TE Connectivity |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Modules |
Impedance |
50 Ohms |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Ordering ID |
239-L001257-01 |
Manufacturer Part Number |
L001257-01 |
Maximum Frequency |
2.7 GHz |
VSWR |
2.6:1 |
Minimum Frequency |
698 MHz |
Gain (Db) |
3.8 dBi |
Antenna Connector |
SMA-Male |
Minimum Operating Temperature |
- 30°C |
Maximum Operating Temperature |
+ 70°C |
Series |
D2D |
IP Rating |
IP67 |
RoHS Compliant |
Yes (By Exemption) |
Product Type |
Cellular Antennas - GSM, LTE, 2G/3G/4G/5G |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ANT-DS-L001257-01-D2D-SATELLITE&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=L001257-01 |
Number of Bands |
8 Band |
Termination Style |
Connector |
Mounting Style |
Panel Mount |
Power Rating |
10 W |
Protocol - Cellular, NBIoT, LTE |
LTE |
Application |
Indoor and Outdoor |
