| Type of Product | Weldon Adaptor |
| Weight | 2.18 Kg |
| Body Material | Steel |
| Series | CAT-V |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Weldon Adaptor |
Weight |
2.18 Kg |
Body Material |
Steel |
Series |
CAT-V |
Country of Origin |
China |
Overall Length |
6.7 inch (169.99 mm) |
Thread Size |
M11 |
Name of Manufacturer/Packer/Importer |
Kantilal & co |
Functional Diameter |
1.75 inch (44 mm) |
Body Length |
9 mm |
Ordering ID |
AA3B20-40 38 101 |
Rotational Speed |
18,000 1/min |
Connection Diameter |
1.5 inch (38 mm) |
Torque (ft/lbs) |
33.1903 ft/lbf |
Connection |
CAT-V -AD/B Central/Flange Coolant - CAT-V40 |
Method |
Balancing by Design |
Body Diameter |
48 mm |
Body Length (inch) |
0.36 inch |
Taper Angle |
45 ° |
Body Diameter (inch) |
1.9 inch |
Functional Length |
4 inch (102 mm) |
Style |
Decentral Over Flange And Axial |
Nominal Diameter |
5/8 inch (16 mm) |
