| Model No | BW63SAS-2P063 |
| Type of Product | Auto Breaker |
| Breaking Capacity | General-purpose type |
| Frame (AF) | 63 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
BW63SAS-2P063 |
Type of Product |
Auto Breaker |
Breaking Capacity |
General-purpose type |
Frame (AF) |
63 |
Trip button |
Included |
Monotaro ID |
50085542 |
Connection Type |
Surface type (screw terminal) |
No. of Pole |
2 Pole |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Application |
AC/DC shared |
Import Country |
Direct Import from Japan |
No. of Elements |
0E |
Rated Current (A) |
63 |
Rated Insulation Voltage (V) |
AC 690/DC 250 |
Rated Impulse Withstand Voltage (kV) |
6 |
Dimension B (Φmm) |
100 |
Dimension A (Φmm) |
50 |
Dimension d |
84 mm |
Dimension C |
60 mm |
Rated Frequency (Hz) |
50-60 |
Rated Operating Voltage (V) |
AC 500/DC 250 |
Withstand Current |
0.8 kA (1s) |
Isolation |
Conformity |
Reverse Connection |
Possible |
Pollution Degree (Environment to Use) |
3 |
