| Model No | BW50EAL-3P020B |
| Type of Product | Breaker |
| Trip button | Included |
| Monotaro ID | 50083643 |
Model No |
BW50EAL-3P020B |
Type of Product |
Breaker |
Trip button |
Included |
Monotaro ID |
50083643 |
Connection Type |
Surface type (screw terminal) |
No. of Pole |
3 Pole |
Rated Sensitivity Current (mA) |
Switch between 30, 100/200/500/1000 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
Rated Breaking Capacity (kA) |
JIS C 8201-2-2 Ann.2：(AC 415V)2.5-(AC 400/380)2.5-(AC 240/230V)5-(AC 100V)5 |
No. of Elements |
3E |
Rated Current (A) |
20 |
Phase / Wire Type |
1Φ3W, 3Φ3W, 1Φ2W |
Rated Impulse Withstand Voltage (kV) |
4 |
Dimension B (Φmm) |
130 |
Overcurrent Tripper Type |
Complete electromagnetic type |
Dimension A (Φmm) |
75 |
Dimension d |
84 mm |
Dimension C |
60 mm |
Rated Frequency (Hz) |
50-60 |
Rated Operating Voltage (V) |
AC 100-230-440 shared |
Reverse Connection |
Impossible |
Pollution Degree (Environment to Use) |
2 |
Operating Time |
(High speed type) 0.1s (maximum) |
Type of Resetting |
Manual Reset or Power Off |
