| Mounting | M14 |
| Type of Product | Stopper Switch |
| Model No | STM14 |
| Monotaro ID | 22190963 |
Mounting |
M14 |
Type of Product |
Stopper Switch |
Model No |
STM14 |
Monotaro ID |
22190963 |
Protection Class |
IP44 |
Operations |
OFF-ON |
Output Specifications |
NPN open collector (ON when approaching) |
Current Consumption (mA) |
12MAX |
Case Material |
SUS303 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Operation Ambient Temperature (°C) |
-20 to 85 (no condensation) |
Allowable Operating Frequency (times/min) |
60 or less |
Head Shape |
hexagonal |
Stroke (mm) |
0.8 |
Cable Material |
Nitrile rubber |
Power Supply Voltage (V) |
DC 5 to 24 |
Cable |
3-core Φ2.8x1m, gray |
Output Current (mA) |
15MAX |
Repeatability (mm) |
±0.002 |
Nut Tightening Torque (Nm) |
18 or less |
Tip Material |
SUS |
Mounting hole dimensions (mm) |
Φ14 |
Static Load Capacity |
10 kN |
