| Mounting | M3 Tightening torque 0.3 Nm |
| Type of Product | Door Switch |
| Model No | STS93 |
| Monotaro ID | 22201174 |
Mounting |
M3 Tightening torque 0.3 Nm |
Type of Product |
Door Switch |
Model No |
STS93 |
Monotaro ID |
22201174 |
Operating Force (N) |
0.8 |
Protection Class |
IP65 |
Operations |
OFF-ON |
Power Supply Voltage |
DC12 to 24 V |
Case Material |
Glass FB reinforced PBT |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Movement Differential (Max.) |
0.1mm or less |
Pretravel (PT) |
03 to 0.8 mm |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Indicator Lamp |
Red |
Stroke (mm) |
8 |
Output Current (mA) |
80 |
Repeatability (mm) |
±0.01 |
Shaft Material |
SUS303 |
