Ships within 19 days
View
View
View
View
| Mounting | M10 |
| Type of Product | Ball Blanker Switch |
| Model No | STMB10B-J |
| Monotaro ID | 22204683 |
Mounting |
M10 |
Type of Product |
Ball Blanker Switch |
Model No |
STMB10B-J |
Monotaro ID |
22204683 |
Operating Force (N) |
0.35 |
Protection Class |
IP65 |
Operations |
ON-OFF |
Output Specifications |
NPN open collector (OFF when approaching) |
Current Consumption (mA) |
12MAX |
Case Material |
SUS303 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
ASA ELECTRONICS INDUSTRY |
Operation Ambient Temperature (°C) |
-20 to 85 (no condensation) |
Allowable Operating Frequency (times/min) |
60 or less |
Head Shape |
screw |
Indicator Lamp |
None |
Stroke (mm) |
1 |
Power Supply Voltage (V) |
DC 5 to 24 |
Cable |
3-core Φ2.8x1m, black |
Output Current (mA) |
15MAX |
Repeatability (mm) |
±0.01 |
Bolt Material |
SUS303 |
Nut Tightening Torque (Nm) |
12 |
Mounting hole dimensions (mm) |
Φ10 |
Nut Material |
SUS303 |
