| Type of Product | Intel Pack Monitor Switch |
| Model No | IP50MSD15DAD0 |
| Output | Relay Contact Output 2 Points (1Ax2, Ll Operation) |
| Type | 2-Point Output Monitor Switch |
Type of Product |
Intel Pack Monitor Switch |
Model No |
IP50MSD15DAD0 |
Output |
Relay Contact Output 2 Points (1Ax2, Ll Operation) |
Type |
2-Point Output Monitor Switch |
Power Consumption |
About 4.5 VA |
Monotaro ID |
7597738 |
Mass (g) |
Approx. 200 (Including Base Socket) |
Case Material |
Heat Resistant Abs Resin |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Azbil Corporation |
Operation Ambient Temperature (°C) |
-5 to 55 |
Terminal Fitting Type |
Wall Mount Or Din Rail Mount |
Specifications |
Additional Processing: With Inspection Report |
Operating Ambient Humidity |
90 % RH or less (no condensation) |
Power Supply Voltage (V) |
AC 100/110/120(50/60 Hz) |
Response Time (seconds) |
0.1 |
Input Impedance |
1000000 Ω |
Input Type |
0 to 10 V |
