| Type of Product | Projection Type Switch |
| Model No | A30PTH10O |
| Type | Non-illuminated type |
| Monotaro ID | 37854607 |
Type of Product |
Projection Type Switch |
Model No |
A30PTH10O |
Type |
Non-illuminated type |
Monotaro ID |
37854607 |
Shape |
Projection (metal ring) |
Mechanical Durability |
500,000 times |
Operating Force (N) |
Approx. 12 (Contact configuration 1a1b) |
Electrical Durability |
500,000 times |
Protection Class |
IP65 oil-proof type |
Rated Operating Current (A) |
AC-15 class (inductive load): 24V / 10, 48V / 10, 110V / 6, 220V / 4, 440V / 1.5 DC-13 class (inductive load): 24V / 6, 48V / 2, 110V / 0.7, 220V /0.3 DC-12 class (resistive load): 24V / 6, 48V / 3, 110V / 2, 220V / 1 |
Rated Insulation Voltage (V) |
AC/DC 600 |
Button Color |
Color |
Contact Configuration |
1A |
Temperature Rise |
40K or less |
Operation Type |
Alternate |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Relative Humidity |
45 to 85% |
Terminal Shape |
Screw terminal |
Name of Manufacturer/Packer/Importer |
Maruyasu Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-20 to 55 |
Insulation Resistance (MOhm) |
100 mohm or more (500 V) |
Contact Resistance (ohm) |
30 mΩ or less |
Mounting Hole Diameter (Φmm) |
30.5(+0.5 to 0) |
Button Shape |
Round (projection) |
Cold Resistance |
-40 to 70℃ |
Heat Resistant Temperature (℃) |
-40 to 70 |
