| Switch Type | ON-OFF (dotted) |
| Type of Product | Wave switch DS-850 series |
| Model No | DS-850S-F2-WD-K |
| Color | Black |
Switch Type |
ON-OFF (dotted) |
Type of Product |
Wave switch DS-850 series |
Model No |
DS-850S-F2-WD-K |
Color |
Black |
Rated Voltage (V) |
AC250 |
Monotaro ID |
38907635 |
Rated Current (A) |
10 |
RoHS Directive |
Correspondence |
No. of Pole |
2 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Terminal Shape |
Tab terminal # 187 (t = 0.5) |
Circuits |
SPST(4P) |
Name of Manufacturer/Packer/Importer |
Miyama Electric Co., Ltd. |
Isolation Voltage |
AC 2000V for 1 minute |
Insulation Resistance (MOhm) |
100 or more (MIN)/DC500V |
Contact Resistance (ohm) |
20 mΩ or less (MAX) |
Circuit configuration |
DPST(4P) |
Current Capacity |
10A250V.AC |
Throw Type |
Single throw |
