| Switch Type | ON-ON |
| Type of Product | Slide Switch |
| Model No | ASE2D-2M-10-Z |
| Standard | UL certified product |
Switch Type |
ON-ON |
Type of Product |
Slide Switch |
Model No |
ASE2D-2M-10-Z |
Standard |
UL certified product |
Monotaro ID |
39221183 |
Withstand Voltage |
250 V AC for 1 minute |
Contact Spacing |
2.54 |
Rating |
Maximum: AC / DC48V 50mA, Minimum: AC / DC20mV 1μA |
Electrical Life (Rated Load) |
Maximum rating: 10000 times, minimum: 50000 times |
Operation Mechanism |
Standard |
Operating Temperature Range |
-20 to +85 |
No. of Pole |
2 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Storage Temperature Range |
-40 to +85 |
Terminal Shape |
P / C terminal |
Name of Manufacturer/Packer/Importer |
Nidec Components (formerly Nidec Copal Electronics/Fujisoku) |
Specifications |
RoHS compliant product |
Insulation Resistance (MOhm) |
500 or more (DC 250 V) |
Contact Resistance (ohm) |
(Initial) 50 or less (AC200μ AV 1.5 mA) |
