| Type of Product | Foot Switch |
| Model No | OFL-VG-SPG |
| Type | Multi-function type |
| Color | Green |
Type of Product |
Foot Switch |
Model No |
OFL-VG-SPG |
Type |
Multi-function type |
Color |
Green |
Rated Voltage (V) |
DC 30 |
Monotaro ID |
8519201 |
Rated Current (A) |
0.1 |
Mass (g) |
260 |
Withstand Voltage |
1,500 V AC for 1 minute |
Protection Class |
IP30 |
Rating |
0.1A-30 V DC (minimum load 5mA-6 V DC, 2mA-12 V DC, 1mA-24 V DC) |
Contact Configuration |
1a |
Cover Material |
Ethylene Vinyl Acetate Polymer |
Body Material |
Polycarbonate resin |
Shock Resistance |
30G |
No. of Port |
1 train |
Rated Carrying Current (A) |
0.1 |
Operating Force |
10 N (1 Kgf) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Osaka Automatic Electric Co., Ltd. |
Operation Ambient Temperature (°C) |
-5 to 45 |
Specifications |
Steel plate with rubber base |
Insulation Resistance (MOhm) |
100 or more (at 500 V DC megger) |
Operating Patterns |
Momentary |
Cable Type |
0.75 mm² 2 core 1.5 m |
