| Type of Product | Foot Switch |
| Model No | OFL-2YV-S3 |
| Material | Aluminum die casting |
| Type | Small device type |
Type of Product |
Foot Switch |
Model No |
OFL-2YV-S3 |
Material |
Aluminum die casting |
Type |
Small device type |
Rated Voltage (V) |
AC250 |
Monotaro ID |
8518422 |
Rated Current (A) |
6 |
Mass (g) |
300 |
Protection Class |
IP20 |
Rating |
6A-250 V AC |
Contact Configuration |
1a (each stage) |
No. of Port |
1 train |
Rated Carrying Current (A) |
6 |
Operating Force |
1st stage 8N, 2nd stage 34N |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Osaka Automatic Electric Co., Ltd. |
Specifications |
Front hinge type |
Operating Patterns |
Momentary (two-stage) |
Built in Switch |
Micro switch V type |
Cable Type |
0.75 mm² 4 core 1 m |
