| Type of Product | Foot Switch |
| Model No | OFL-VG-S3 |
| Material | Aluminum die casting |
| Type | Small device type |
Type of Product |
Foot Switch |
Model No |
OFL-VG-S3 |
Material |
Aluminum die casting |
Type |
Small device type |
Rated Voltage (V) |
DC 30 |
Monotaro ID |
8518483 |
Rated Current (A) |
0.1 |
Mass (g) |
330 |
Protection Class |
IP30 |
Rating |
0.1A-30 V DC (minimum load 5mA-6 V DC, 2mA-12 V DC, 1mA-24 V DC) |
Contact Configuration |
1c |
No. of Port |
1 train |
Rated Carrying Current (A) |
0.1 |
Operating Force |
10 N (1 Kgf) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Osaka Automatic Electric Co., Ltd. |
Specifications |
Front hinge type |
Operating Patterns |
Momentary |
Built in Switch |
V type (gold clad contact) |
Cable Type |
0.5 mm² 3-core 2 m |
Minimum Load Current |
38384 mA |
Minimum Load Voltage |
DC 6/12/24 V |
