| Type of Product | Foot Switch |
| Model No | OFL-VG-M4 |
| Material | ABS resin |
| Type | Mini type for equipment |
Type of Product |
Foot Switch |
Model No |
OFL-VG-M4 |
Material |
ABS resin |
Type |
Mini type for equipment |
Color |
Black |
Rated Voltage (V) |
DC 30 |
Monotaro ID |
8518623 |
Mass (g) |
200 |
Protection Class |
IP30 |
Rating |
0.1A-30 V DC (minimum load / 2mA-12 V DC, 1mA-24 V DC) |
Contact Configuration |
1c |
No. of Port |
1 train |
Rated Carrying Current (A) |
0.1 |
Operating Force |
10 N (1.0 Kgf) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Osaka Automatic Electric Co., Ltd. |
Specifications |
Rear hinge type |
Operating Patterns |
Momentary |
Built in Switch |
V type (gold clad contact) |
Cable Type |
0.5 mm² 3 core 2 m |
