| Type of Product | Ultra Compact Basic Switch |
| Model No | SS-5-2D |
| Rated Voltage (V) | AC 125 |
| Monotaro ID | 66554057 |
Type of Product |
Ultra Compact Basic Switch |
Model No |
SS-5-2D |
Rated Voltage (V) |
AC 125 |
Monotaro ID |
66554057 |
Rated Current (A) |
5 |
Mass (g) |
1.6 (in the case of pin push button type) |
Allowable Operating Speed |
0.1 mm-1m/S |
Heat Resistance Temperature |
85℃ (General Type) |
Electric Shock Protection Class |
Class I |
Terminal Type |
Printed circuit board terminal |
Actuator Type |
Pin push button type |
Withstand Voltage |
Between terminals of the same pole: AC1000V + 50 / 60Hz + 1min ・ Between charging metal part and ground: AC1500V + 50 / 60Hz + 1min ・ Between each terminal and non-charging metal part: AC1500V + 50 / 60Hz + 1min (when using separator) |
Mechanical Durability |
30 million operations or more (60 operations / min) |
Minimum Applicable Load |
DC 5 V 160 mA |
PTI (Proof Tracking Index) |
175 |
Electrical Durability |
200,000 operations or more (30 operations / min) |
Protection Class |
IEC IP40 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
Frequency 10-55Hz, double amplitude 1.5mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to 85 60% RH or less (with no icing or condensation) |
Insulation Resistance (MOhm) |
100 or more (with DC 500 V insulation resistance meter) |
Contact Resistance (ohm) |
30 mΩ or less (initial value) |
