Ships within 25 days
View
View
View
View
| Switch Type | Self-recovery mechanism |
| Type of Product | Seal Type Compact Basic Switch |
| Model No | D2VW-01L1-1M-0 |
| Rated Voltage (V) | AC 125, DC 30 |
Switch Type |
Self-recovery mechanism |
Type of Product |
Seal Type Compact Basic Switch |
Model No |
D2VW-01L1-1M-0 |
Rated Voltage (V) |
AC 125, DC 30 |
Monotaro ID |
46446364 |
Rated Current (A) |
0.1 |
Electric Shock Protection Class |
ClassⅠ |
Terminal Type |
With lead wire |
Actuator Type |
Hinge / lever type |
Mechanical Durability |
10 million times or more (60 times/min) |
PTI (Proof Tracking Index) |
175 |
Electrical Durability |
1,000,000 times or more (30 times/min) |
Protection Class |
IEC IP67 |
Operating Temperature Range |
-40 To 85℃ 60% RH or less (With No Icing Or Condensation) |
Contact Specifications |
Double throw type |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
Frequency 10-55Hz, double amplitude 1.5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Remark |
Confirm Delivery Date Each Time |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
200 mΩ or less |
