| Type of Product | Subminiature Basic Switch |
| Model No | D2S-5L-F |
| Rated Voltage (V) | AC 125/AC 250 |
| Monotaro ID | 46550917 |
Type of Product |
Subminiature Basic Switch |
Model No |
D2S-5L-F |
Rated Voltage (V) |
AC 125/AC 250 |
Monotaro ID |
46550917 |
Mass (g) |
1.6 (Pin push button type) |
Allowable Operating Speed |
0.1Mm To 1 m/s (Pin Pushbutton Type) |
Terminal Type |
Solder Terminal |
Actuator Type |
Hinge / lever type |
Withstand Voltage |
Between homopolar terminals: AC 1000 V 50 / 60 Hz 1 min Between charged metal part and ground, Between each terminal and non-charged metal part: Between each terminal and non-charged metal part Value when using AC 1500 V 50 / 60 Hz 1 min separator |
Mechanical Durability |
30 million operations or more (60 operations / min) |
Minimum Applicable Load |
DC 5 V 160 mA |
Inrush current (A) |
(Normally closed circuit) up to 20, (normally open circuit) up to 10 |
Electrical Durability |
200,000 operations or more (30 operations / min) |
Operating Humidity Range |
85% RH or less (at +5 to + 35 ° C) |
Protection Class |
Ip40 |
Rating |
AC 125 V 5A/AC 250 V 3 Amp |
Contact Configuration |
1c (single pole double throw type) |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
Frequency 10 to 55Hz, double amplitude 1.5 mm (operating limit position) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to +85 60% RH or less (with no icing or condensation) |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
