Ships within 25 days
View
View
View
View
| Type of Product | Mounting Seal Type Basic Switch |
| Model No | D2FW-G081M |
| Rated Voltage (V) | DC 30 |
| Monotaro ID | 46431725 |
Type of Product |
Mounting Seal Type Basic Switch |
Model No |
D2FW-G081M |
Rated Voltage (V) |
DC 30 |
Monotaro ID |
46431725 |
Allowable Operating Speed |
1 m m/s to 500 m m/s |
Electric Shock Protection Class |
Class I |
Terminal Type |
Lead |
Actuator Type |
Long leaf lever type |
Mechanical Durability |
300,000 times or more |
Electrical Durability |
100,000 times or more (20 times / min) |
Protection Class |
IP67 |
Resistive Load |
0.1A |
Type of Sign |
Screw mounting |
Contact Configuration |
1c (single pole double throw type) |
Ambient Humidity (% RH) |
95 or less |
Operation Type |
Snap action |
Rated Carrying Current (A) |
0.1 |
Operating Force |
2.94 N |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Mass (Kg) |
About 0.0104 |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
100 mΩ or Less (initial value) |
Ambient Temperature (℃) |
-40 to 85 (no freezing or condensation) |
Lead Wire |
AVS0.51 core / length: 0.3m / drawer direction: downward / connection to terminal (black: COM red: NC blue: NO) |
