| Type of Product | Sealed Ultra-Small Basic Switch |
| Model No | D2QW-C183ML |
| Rated Voltage (V) | DC 30/14 |
| Monotaro ID | 66548292 |
Type of Product |
Sealed Ultra-Small Basic Switch |
Model No |
D2QW-C183ML |
Rated Voltage (V) |
DC 30/14 |
Monotaro ID |
66548292 |
Allowable Operating Speed |
1 to 500 mm/s |
Electric Shock Protection Class |
ClassⅠ |
Terminal Type |
With lead wire (Left-out type) |
Actuator Type |
Bent, leaf, lever type |
Mechanical Durability |
500,000 operations or more (30 operations/min) |
PTI (Proof Tracking Index) |
175 |
Electrical Durability |
DC30V 0.1A 200,000 times or more, DC14V 10mA 500,000 times or more (20 times/min) |
Protection Class |
IEC IP67 (excluding terminals) |
Rating |
Silver Plating Contact DC 5 V 1 mA to DC 30 V 0.1 Amp |
Terminal |
With lead wire (Left-out type) |
Withstand voltage (V / min) |
Between terminals of the same polarity: AC600 (50/60 Hz), Between live metal parts and earth: AC1500 (50/60 Hz), Between each terminal and non-live metal parts: AC1500 (50/60 Hz) |
Contact Specifications |
1a type (normally open type) |
Cover |
M3 screw mounting |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
Frequency: 10 to 55 Hz, amplitude: 1.5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Remark |
Confirm Delivery Date Each Time |
Operation Ambient Temperature (°C) |
-40 To 85 60% Rh Or Less (With No Icing Or Condensation) |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
150 mΩ or less (initial value) |
