| Switch Type | Category: D (IEC335) |
| Type of Product | Compact Enclosed Switch |
| Model No | ZC-N2155-MRVCT1M |
| Rated Voltage (V) | Ac125/250, Dc8/14/30/125/250 |
Switch Type |
Category: D (IEC335) |
Type of Product |
Compact Enclosed Switch |
Model No |
ZC-N2155-MRVCT1M |
Rated Voltage (V) |
Ac125/250, Dc8/14/30/125/250 |
Monotaro ID |
66540303 |
Shape |
General-purpose horizontal type |
Mass (g) |
Approx. 92 (for ZC-Q22 (21) 55) |
Terminal Type |
Molded terminal type |
Actuator Type |
Seal / cross / roller / plunger type |
Withstand Voltage |
Between same pole terminals AC 1000 V 50/60 Hz 1min ・ Between each terminal and non-charged metal part AC2000V 50 / 60H 1min |
Mechanical Durability |
10 Million Times Or More |
Protection Class |
IP67 |
Applicable Standard |
Ul/Csa/Tuv(En60947-1, En60947-5-1)/Ccc(Gb14048.5) |
Operation Indicator Lamp |
None |
Cable Length (m) |
1 (VCT 3 cores) |
Operation Environment |
Pollution degree: 3 (IEC947-5-1) |
Rated Insulation Voltage (V) |
AC1000 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz Double Amplitude 1.5 mm |
Terminal Shape |
Molded terminal type |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Contact Resistance (ohm) |
15 mΩ or less (Initial Value, Built-In Switch Only) |
