| Type of Product | Sealed Ultra-Small Basic Switch |
| Model No | D2JW-01K13-MD |
| Rated Voltage (V) | DC 30 |
| Monotaro ID | 66547382 |
Type of Product |
Sealed Ultra-Small Basic Switch |
Model No |
D2JW-01K13-MD |
Rated Voltage (V) |
DC 30 |
Monotaro ID |
66547382 |
Allowable Operating Speed |
1 mm to 250 m m/s (in case of pin push button type) |
Terminal Type |
With lead wire |
Actuator Type |
Hinge / lever type |
Withstand Voltage |
Between same-polarity terminals: AC600V 50/60 Hz 1 min, Between live metal parts and earth, between each terminal and non-live metal parts: AC 1000 V 50/60 Hz 1 min |
Mechanical Durability |
1,000,000 times or more (60 times / min) |
Minimum Applicable Load |
DC 5 V 1 mA |
Ambient Humidity to Use |
35 to 98% RH (at +5 to + 35°C) |
Inrush current (A) |
Normally closed: Max. 0.1 Normally open: Max. 0.1 |
Electrical Durability |
100,000 times or more (30 times / min) |
Return Force (N) |
0.15 min |
Protection Class |
IEC IP67 |
Rating |
DC 30 V 0.1 Amp (resistive load) |
Contact Specifications |
Crossbar |
Operating Force |
Up to 0.80 N |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
Frequency 10 to 55Hz, double amplitude 1.5 mm (operating limit position) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-40 To 85 60% Rh Or Less (With No Icing Or Condensation) |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
140 mΩ or Less (initial value) |
