| Type of Product | Safety Door Switch |
| Model No | D4NS-2CD |
| Type | Standard type |
| Monotaro ID | 46513686 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Safety Door Switch |
Model No |
D4NS-2CD |
Type |
Standard type |
Monotaro ID |
46513686 |
Allowable Operating Speed |
0.05 to 0.5m/s |
Electric Shock Protection Class |
Class II (double insulation) |
Mechanical Durability |
1,000,000 times or more |
Minimum Applicable Load |
DC5 V 1 mA resistance load (N le Vel reference Value) |
Electrical Durability |
500,000 times or more (AC250V 3A, resistive load)<br> Over 300,000 times (AC250V 10A, resistive load) |
Protection Class |
IP67(EN60947-5-1) |
Rated Frequency (Hz) |
50/60 |
Rated Insulation Voltage (V) |
(Ui)300 |
Pollution Degree (Environment to Use) |
Pollution degree 3 (EN60947-5-1) |
Shock Resistance |
1000m / s² or more |
Mounting Side |
(Head) 4 orientations available (front view at shipping) |
Rated Impulse Withstand Voltage (kV) |
Between terminals of the same polarity: 2.5, Between terminals of different polarities: 4, Between each terminal and non-current-carrying metal parts: 6 |
Operating Force |
(Direct opening) Standard type minimum 60N<br> (Direct opening) High load type min. 80N |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Head Material |
Metal |
Vibration Resistance (Malfunction) |
10-55Hz 0.75 mm single amplitude |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-30 to 70 (but no freezing) |
Pack of |
1 Pcs |
Insulation Resistance (MOhm) |
o Ver 100 |
Contact Resistance (ohm) |
25 or less |
