| Type of Product | Compact Enclosed Switch |
| Model No | SHL-W3155-01 |
| Type | Micro load type |
| Rated Voltage (V) | AC125, DC8, 14, 30 |
Type of Product |
Compact Enclosed Switch |
Model No |
SHL-W3155-01 |
Type |
Micro load type |
Rated Voltage (V) |
AC125, DC8, 14, 30 |
Monotaro ID |
46542833 |
Shape |
General-purpose horizontal type |
Actuator Type |
One-way motion hinge roller lever type |
Withstand Voltage |
(between terminals of the same polarity)<br> AC1000V 50/60Hz 1min<br> (Between each terminal and non-current-carrying metal parts)<br> AC2000V 50/60Hz 1min/Uimp 2.5kV(EN60947-5-1) |
Mechanical Durability |
10 million times or more |
Protection Class |
IP67(EN60947-5-1) |
Rated Frequency (Hz) |
50/60 |
Operation Indicator Lamp |
None |
Rated Insulation Voltage (V) |
(Ui)150(EN60947-5-1) |
Contact Configuration |
1C |
Wire Diameter (mm) |
(Lead wire) 0.18 |
Shock Resistance |
1000 m/s² or more |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10-55Hz double amplitude 1.5mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (no icing) |
Insulation Resistance (MOhm) |
100 or more (with DC 500 V mega) |
Contact Resistance (ohm) |
15 mΩ or less (initial value, built-in switch only) |
