| Type of Product | Ultra-Small Basic Switch |
| Model No | D2SW-01L2DS |
| Rated Voltage (V) | DC 30 |
| Monotaro ID | 66548502 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Ultra-Small Basic Switch |
Model No |
D2SW-01L2DS |
Rated Voltage (V) |
DC 30 |
Monotaro ID |
66548502 |
Rated Current (A) |
0.1 |
Electric Shock Protection Class |
Class I |
Terminal Type |
Free standing terminals for printed circuit boards |
Actuator Type |
Hinge / roller / lever type |
Withstand Voltage |
Between same-polarity terminals: AC600V 50/60Hz 1min<br> Between live metal parts and earth: AC1500V 50/60Hz 1min<br> Between each terminal and non-current-carrying metal parts: AC1500V 50/60Hz 1min<br> (When using a separator) |
Mechanical Durability |
5 million operations or more (60 operations / min) |
Minimum Applicable Load |
DC5 V 1 mA |
PTI (Proof Tracking Index) |
175 |
Inrush current (A) |
Normally closed circuit: max. 1, normally open circuit: max. 1 |
Electrical Durability |
200,000 operations or more (30 operations / min) |
Protection Class |
IEC IP67 (excluding terminals) |
Applicable Standard |
UL/cUL Standards |
Shock Resistance |
Up to 1000 m/s ² |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
Frequency 10-55Hz, double amplitude 1.5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-40 to 85 60% RH or less (with no icing or condensation) |
Insulation Resistance (MOhm) |
100 or more (with DC500 V insulation resistance meter) |
Contact Resistance (ohm) |
50 or less (initial value) |
