| Type of Product | Regular-Use Enclosed Switch |
| Model No | XE-N21-2YG1 |
| Type | Seal type |
| Rated Voltage (V) | DC 8, 14, 30, 125, 250 |
Type of Product |
Regular-Use Enclosed Switch |
Model No |
XE-N21-2YG1 |
Type |
Seal type |
Rated Voltage (V) |
DC 8, 14, 30, 125, 250 |
Monotaro ID |
66532077 |
Mass (g) |
About 260-280 |
Allowable Operating Speed |
0.01 mm to 0.5 m/s |
Actuator Type |
Seal / cross / roller / plunger type |
Withstand Voltage |
Between terminals of the same pole: AC 1000V 50 / 60Hz 1min ・ Between charging metal part and ground, between each terminal and non-charging metal part: AC1500 V 50 / 60H 1min |
Mechanical Durability |
1,000,000 times or more |
Inrush current (A) |
Constant maximum: closed circuit: 30, open circuit: 15 |
Electrical Durability |
100,000 operations or more (125 V DC, 10 A resistance load) |
Protection Class |
IP65 |
Rated Frequency (Hz) |
50/60 |
Applicable Standard |
UL / CSA / CCC standard |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz, 1.5 mm double amplitude (at the limit position) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Terminal Fitting Type |
Side mounting |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Contact Resistance (ohm) |
15 mΩ or Less (initial value) |
