Ships within 19 days
Model No
View
View
View
View
| Switch Type | Category / D (IEC335) |
| Type of Product | Compact Enclosed Switch |
| Model No | ZC-N2255-L4 |
| Rated Voltage (V) | Ac125/250, Dc8/14/30/125/250 |
Switch Type |
Category / D (IEC335) |
Type of Product |
Compact Enclosed Switch |
Model No |
ZC-N2255-L4 |
Rated Voltage (V) |
Ac125/250, Dc8/14/30/125/250 |
Monotaro ID |
39111956 |
Shape |
General-purpose horizontal type |
Mass (g) |
Approx. 92 (for ZC-Q22 (21) 55) |
Actuator Type |
Sealed roller plunger type |
Withstand Voltage |
Between same pole terminals AC 1000 V 50/60 Hz 1min ・ Between each terminal and non-charged metal part AC2000V 50 / 60H 1min |
Mechanical Durability |
10 Million Times Or More |
Minimum Applicable Load |
DC 5 V 160 mA |
Protection Class |
IP67 |
Applicable Standard |
Ul/Csa/Tuv(En60947-1, En60947-5-1)/Ccc(Gb14048.5) |
Operation Indicator Lamp |
With (for DC 24 V) |
Operation Environment |
Pollution degree: 3 (IEC947-5-1) |
Rated Insulation Voltage (V) |
AC1000 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz Double Amplitude 1.5 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (No Icing) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Contact Resistance (ohm) |
15 mΩ or less (Initial Value, Built-In Switch Only) |
