| Type of Product | Switching Power Supply |
| Model No | S8VS-48024A-F |
| Type | Replacement time notification function type with display monitor |
| Connection Type | Terminal block |
Type of Product |
Switching Power Supply |
Model No |
S8VS-48024A-F |
Type |
Replacement time notification function type with display monitor |
Connection Type |
Terminal block |
Storage Temperature |
-25 to 65℃ |
Monotaro ID |
39096574 |
Shape |
Directly on DIN rail |
Mass (g) |
1700 or less |
Ambient Humidity to Use |
25-85% (Storage humidity 25-90%) |
Function |
Undervoltage detection display: Yes (switchable), displayed on 7-segment LED (character height 8 mm) |
Structure |
Type with cover |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Outer Dimensions |
150x115x127.2 mm |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to 60 (no condensation or freezing) |
Specifications |
UL Class2 output (UL1310): Not compliant |
Insulation Resistance (MOhm) |
Between 100 or more (collective output, collective alarm output) and (collective input, ground [earth]) at 500 V DC |
Rated Output Current (A) |
20 |
Rated Input Voltage (V) |
AC 100 to 240 |
Power Factor |
0.95 or more |
Capacity (W) |
480 |
Output Voltage (V) |
DC 24 |
Alarm Output |
Shared sink (emitter COM) / source (collector COM) |
Recommended Timing to Replace |
Notification display: Yes (switchable), Notification output: Yes (transistor output) DC30V max. 50mA max. |
