| Type of Product | Ultra-Small Basic Switch |
| Model No | D2F-FL-T |
| Type | Low load operation type |
| Rated Voltage (V) | AC 125 |
Type of Product |
Ultra-Small Basic Switch |
Model No |
D2F-FL-T |
Type |
Low load operation type |
Rated Voltage (V) |
AC 125 |
Monotaro ID |
46503633 |
Allowable Operating Speed |
5 mm to 500 m m/s |
Terminal Type |
Free standing terminals for printed circuit boards |
Actuator Type |
Hinge / lever type |
Withstand Voltage |
Between same-polarity terminals: AC600V 50/60 Hz 1 min, Between live metal parts and earth, between each terminal and non-live metal parts: AC 1500 V 50/60 Hz 1 min |
Mechanical Durability |
1,000,000 times or more (60 times / min) |
Minimum Applicable Load |
DC 5 V 100 mA (reference value) |
Electrical Durability |
30,000 times or more (30 times / min) |
Operating Humidity Range |
85% RH or less (at 5 to 35°C) |
Protection Class |
IEC IP40 |
Contact Type |
1c (double throw type) |
Resistive Load |
(AC 125 V)1A, (DC 30 V)0.5 Amp |
Operating Temperature Range |
-40 To 85 60% Rh Or Less ℃ (With No Icing Or Condensation) |
Contact Configuration |
1c (single pole double throw type) |
Contact Specifications |
Crossbar |
Rated Carrying Current (A) |
1 |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz, double amplitude 1.5 mm (value at the operation limit position, contact closing or opening within 1ms) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
100 Or More (With Dc500V Insulation Resistance Meter) |
Contact Resistance (ohm) |
50 mΩ or Less (initial value) |
