| Type of Product | Regular-Use Enclosed Switch |
| Type | Seal type |
| Rated Voltage (V) | AC125、250、480、DC125、250 |
| Monotaro ID | 35501426 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Regular-Use Enclosed Switch |
Type |
Seal type |
Rated Voltage (V) |
AC125、250、480、DC125、250 |
Monotaro ID |
35501426 |
Shape |
General-purpose horizontal type |
Mass (g) |
About 260-280 |
Allowable Operating Speed |
0.01mm to 0.5m/s |
Actuator Type |
Sealed roller plunger type |
Withstand Voltage |
Between terminals of the same pole: AC1000V 50 / 60Hz 1min ・ Between charging metal part and ground, between each terminal and non-charging metal part: AC2000V 50 / 60H 1min |
Mechanical Durability |
Over 10 million times<br> (Ambient temperature: 5 to 35°C, ambient humidity: 40 to 70% RH) |
Inrush current (A) |
Constant maximum: closed circuit: 30, open circuit: 15 |
Electrical Durability |
Over 500,000 times (AC250V 15A resistive load)<br> (Ambient temperature: 5 to 35°C, ambient humidity: 40 to 70% RH) |
Protection Class |
IP65 |
Rated Frequency (Hz) |
50/60 |
Terminal Temperature Rising |
50deg or less |
Applicable Standard |
UL / CSA / CCC standard |
Contact Configuration |
1C Contact |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz, 1.5 mm double amplitude (at the limit position) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10-80 (no icing) |
Terminal Fitting Type |
Side diagonal mounting |
Manufacturer Part Number |
ZV2-N22-2 |
Insulation Resistance (MOhm) |
100 or more (with DC500V mega) |
Contact Resistance (ohm) |
15 or less (initial value) |
