| Type of Product | Basic Switch |
| Model No | Z-15GW2255-M19L0.5M |
| Type | Standard |
| Rated Voltage (V) | AC125, 250, 500, DC8, 14, 30, 125, 250 |
Type of Product |
Basic Switch |
Model No |
Z-15GW2255-M19L0.5M |
Type |
Standard |
Rated Voltage (V) |
AC125, 250, 500, DC8, 14, 30, 125, 250 |
Monotaro ID |
66538745 |
Mass (g) |
About 22-58 |
Allowable Operating Speed |
0.01 mm to 1m / s (value of push button) |
Terminal Type |
Molded Terminals |
Actuator Type |
Hinge / roller / short lever type |
Withstand Voltage |
(Between terminals of the same polarity) AC1000V 50/60Hz 1min, (Between live metal parts and earth, between each terminal and non-live metal parts) AC2000V 50/60Hz 1min |
Mechanical Durability |
10 million times or more |
Minimum Applicable Load |
DC 5 V 160 mA |
Electrical Durability |
500,000 times or more |
Protection Class |
Equivalent to IP62 (excluding terminals) |
Applicable Standard |
UL, CSA, TUV(EN61058-1), CCC(GB14048.5) |
Contact Configuration |
1C |
Shock Resistance |
Up to 1000 m/s² |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55Hz, double amplitude 1.5mm (malfunction 1ms or less) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-15-80 (no icing) |
Insulation Resistance (MOhm) |
100 or more (with DC 500 V mega) |
Contact Resistance (ohm) |
15 mΩ or less (initial value) |
Dimensions (H x W x D) (mm) |
42.1x49.2x17.45 |
