Ships within 19 days
Actuator Type
Model No
View
View
View
View
| Type of Product | Magnetic Blow-Off Basic Switch |
| Model No | X-10GS-B |
| Rated Voltage (V) | DC125 |
| Monotaro ID | 39101797 |
Type of Product |
Magnetic Blow-Off Basic Switch |
Model No |
X-10GS-B |
Rated Voltage (V) |
DC125 |
Monotaro ID |
39101797 |
Rated Current (A) |
10 |
Mass (g) |
Approx. 27-63 |
Allowable Operating Speed |
0.1Mm To 1 m/s (Pin Pushbutton Type) |
Electric Shock Protection Class |
ClassⅠ |
Terminal Type |
Screw terminal (Internal tooth washer) |
Actuator Type |
Spring thin push button type |
Withstand Voltage |
Between homopolar terminals, between charged metal and ground, between each terminal and non-charged metal: AC 1500 V 50 / 60 Hz 1 min |
Mechanical Durability |
1,000,000 times or more |
Ambient Humidity to Use |
35 to 85%Rh |
PTI (Proof Tracking Index) |
175 |
Electrical Durability |
100,000 times or more |
Protection Class |
IP00 |
Contact Configuration |
1c (single pole double throw type) |
Shock Resistance |
Up To 1000 m/s² |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Shock Resistance (Malfunction) |
Max.300 m/s² (Pin push button type) (Malfunction within 1ms) |
Vibration Resistance (Malfunction) |
10 to 55 Hz, double amplitude 1.5 mm (malfunction 1ms or less) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25-80 (no icing) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Contact Resistance (ohm) |
15 mΩ or Less (initial value) |
Sensor Shape |
Rectangular |
