| Type of Product | Reed Switch |
| Maximum Operating Temperature | 125°C |
| Width | 2.5 mm |
| Depth | 54 mm |
Type of Product |
Reed Switch |
Maximum Operating Temperature |
125°C |
Width |
2.5 mm |
Depth |
54 mm |
Contact Material |
PGM Alloy |
Contact Resistance |
100 mΩ |
Contact Configuration |
SPCO |
Series |
SW |
Length |
20.3 mm |
Country of Origin |
United Kingdom |
Minimum Operating Temperature |
-20°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Pack of |
5 Pcs |
Maximum Switching Voltage |
300 V |
Maximum Switching Current |
1.5 Amp |
Maximum switching power (W) |
70 W |
Mount Type |
Through Hole Mount |
Operating Time Including Bounce |
0.8 ms |
AT Value Range |
20 to 25 AT |
Maximum Release Time |
0.1 ms |
Standards/Approvals |
No |
