| Type of Product | Wireless Switch Transmitter |
| Model No | ZB5RTA331 |
| Type | Type III |
| Standard | IEC 60947-1, IEC 60947-5-1, UL 508, CSA C22.2 No 14 |
Type of Product |
Wireless Switch Transmitter |
Model No |
ZB5RTA331 |
Type |
Type III |
Standard |
IEC 60947-1, IEC 60947-5-1, UL 508, CSA C22.2 No 14 |
Monotaro ID |
63596594 |
Protection Class |
IP65 (front), IP30 (rear) (compliant with IEC 60529) |
Width (mm) |
30 |
Height (mm) |
41.5 |
Operating Temperature Range |
-40 to 70 ℃ |
Series |
XB5R |
Depth (mm) |
42 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Mass (Kg) |
0.045 |
Specifications |
●Modulation technique：O-QPSK |
No. of Channels |
16 |
Head Shape |
Shape of signaling unit：Round |
Frequency Band (MHz) |
5 |
Detection Distance |
Approximately 100m (transmitter and receiver in free space), approximately 25m (transmitter is in plastic box type XAL D. Receiver is in metal enclosure) |
Transmitting Power |
3 mW |
