| Type of Product | Wireless Switch Transmitter |
| Model No | ZB5RTC2 |
| Type | Product or Component：Wireless and batteryless transmitter, Operator：spring return push-button with transmitter, Antenna：Omnidirectional |
| Standard | IEC 60947-1, IEC 60947-5-1, UL 508, CSA C22.2 No 14 |
Type of Product |
Wireless Switch Transmitter |
Model No |
ZB5RTC2 |
Type |
Product or Component：Wireless and batteryless transmitter, Operator：spring return push-button with transmitter, Antenna：Omnidirectional |
Standard |
IEC 60947-1, IEC 60947-5-1, UL 508, CSA C22.2 No 14 |
Monotaro ID |
63597608 |
Mechanical Durability |
1,000,000 cycles |
Operating Force (N) |
10 N CO changing electrical state |
Protection Class |
IP66 IEC 60529 front face), IP67 IEC 60529 front face), IP69 IEC 60529 front face), IP69K IEC 60529 front face) |
Width (mm) |
27.8 |
Height (mm) |
42.75 |
Operating Temperature Range |
-40 to 70 ℃ |
Series |
XB5R |
Depth (mm) |
43 |
Shock Resistance |
25gn6ms(6000 shocks IEC 60068-2-27), 30gn18ms(half sine wave acceleration IEC 60068-2-27), 50gn11ms(half sine wave acceleration IEC 60068-2-27) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Storage Temperature Range |
-40 to 70 ℃ |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Specifications |
●Modulation technique：O-QPSK |
No. of Channels |
16 |
Head Shape |
Shape of signaling unit：Round |
Frequency Band (MHz) |
5 |
Maximum Power Consumption (mW) |
1 |
Transmission Frequency (MHz) |
2405 |
Transmitting Power |
3 mW |
Allowable Relative Humidity (%) |
95 (no condensation) |
