| Battery Type | 4S Lithium-ion / LiPo |
| Type of Product | BMS Lithium Battery Protection Board With Balance |
| Material | PCB & Electronic Components |
| Model No | 1xBAT-4S-20A-Li-Ion |
Battery Type |
4S Lithium-ion / LiPo |
Type of Product |
BMS Lithium Battery Protection Board With Balance |
Material |
PCB & Electronic Components |
Model No |
1xBAT-4S-20A-Li-Ion |
Peak current |
30 Amp |
Charging Current |
1 A – 10 A |
Nominal Voltage |
12 V |
Country of Origin |
India |
Package Contains |
1 x BMS Battery Protection Board |
Name of Manufacturer/Packer/Importer |
AMICIKART ONLINE SERVICES PRIVATE LIMITED |
Special Features |
Auto Recovery, Short Circuit Protection, Multi Protection System |
Charge Voltage |
16.8 V – 17 V |
Balancing Current |
40 mA |
Over Discharge Protection Voltage |
2.8V ± 0.08V |
Cell Balancing |
Yes |
Overcharge Protection |
4.235 V ± 0.025 V |
