| Type of Product | Ball Bearing for Unit |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | NTN Corporation |
| Model No | UCS212LN |
Type of Product |
Ball Bearing for Unit |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Model No |
UCS212LN |
Shape |
Cylindrical hole type |
Shank Diameter (Φmm) |
60 |
Import Country |
Direct Import from Japan |
Monotaro ID |
407863 |
Load Rank |
For light loads |
Dimensions C (mm) |
27 |
Dimensions B (mm) |
2.85 |
Dimension D1 (mm) |
106.81 |
Outer Diameter D (Φmm) |
110 |
Dimension d4 (mm) |
77 |
Width B (mm) |
65.099999999999994 |
Dimension S1 (mm) |
39.700000000000003 |
Mass (Kg) |
1.59 Kg (Reference) |
Dimensions g (mm) |
10 |
Dimension S |
25.4 mm |
Dimension ds (mm) |
M10×1.25 |
Basic Static Load Rating (kN) |
36 |
Basic Dynamic Load Rating (kN) |
52.5 |
Inner Diameter d (Φmm) |
60 |
Dimensions A (mm) |
4.4000000000000004 |
Chamfer Dimension r1 (mm) |
2 (minimum) |
