Ships within 25 days
View
View
View
View
| Type of Product | Ball Bearing for Unit |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | NTN Corporation |
| Model No | UCS209LN |
Type of Product |
Ball Bearing for Unit |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
NTN Corporation |
Model No |
UCS209LN |
Shape |
Cylindrical hole type |
Shank Diameter (Φmm) |
45 |
Import Country |
Direct Import from Japan |
Monotaro ID |
407836 |
Load Rank |
For light loads |
Dimensions C (mm) |
22 |
Dimensions B (mm) |
2.0499999999999998 |
Dimension D1 (mm) |
81.81 |
Outer Diameter D (Φmm) |
85 |
Dimension d4 (mm) |
57.5 |
Width B (mm) |
49.2 |
Dimension S1 (mm) |
30.2 |
Mass (Kg) |
0.7 (reference) |
Dimensions g (mm) |
8 |
Dimension S |
19 mm |
Dimension ds (mm) |
M8×1 |
Basic Static Load Rating (kN) |
20.399999999999999 |
Basic Dynamic Load Rating (kN) |
32.5 |
Inner Diameter d (Φmm) |
45 |
Dimensions A (mm) |
3.5 |
Chamfer Dimension r1 (mm) |
1.5 (minimum) |
Mass (g) |
700 g (reference) |
