Mean-Well Misc Switch Mode Power Supply Smps

Showing 29 out of 29 products

Sort by

Recommended New Price : Low to High Price : High to Low

Ships within 4 days

MEANWELL EDR-120-12 Output Current 10 A Switched Mode Power Supply

By Mean Well

₹3,185

EDR-120 is one economical slim 120W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 40mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 90VAC to 264VAC and conforms to EN61000-3-2, the norm the European Union regulates for harmonic current.
EDR-120 is designed with metal housing that enhances the unit's power dissipation. With working efficiency up to 88.5%, the entire series can operate at the ambient temperature between -20°C and 60°C under air convection. It is equipped with constant current mode for over-load protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus (UL508, TUV EN60950-1, and etc.) make EDR-120 a very competitive power supply solution for industrial applications. Input Voltage: 90-264 VAC, 127-370 VDC Output Voltage: 12 V AC Voltage: 12 ~ 14 V, Dimension: 113.5x40x125.2 mm

Add to Cart Buy Now

Ships within 5 days

MEANWELL RS-15-5 Output Current 3 A Switched Mode Power Supply

By Mean Well

₹1,014

.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg .tg-e3zv{font-weight:bold}
.tg .tg-rycn{font-weight:bold;text-decoration:underline;background-color:#ffcc67;text-align:center}
.tg .tg-9hbo{font-weight:bold;vertical-align:top}
.tg .tg-yw4l{vertical-align:top}
MODEL - RS-15-5
OUTPUT
Features
Attributes
DC VOLTAGE
5V
RATED CURRENT
3A
CURRENT RANGE
0 ~ 3A
RATED POWER
15W
RIPPLE & NOISE
80mVp-p
VOLTAGE ADJ. RANGE
4.75 ~ 5.5V
VOLTAGE TOLERANCE
±2.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.5%
INPUT
VOLTAGE RANGE
85 ~ 264VAC 120 ~ 370VDC
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY (Typ.)
77%
AC CURRENT (Typ.)
0.35A/115VAC 0.25A/230VAC
INRUSH CURRENT (Typ.)
COLD START 65A / 230VAC
LEAKAGE CURRENT
<2mA / 240VAC
Universal AC input / Full range
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
LED indicator for power on
100% full load burn-in test
No load power consumption<0.5W
All using 105°C long life electrolytic capacitors
Withstand 300VAC surge input for 5 second
High operating temperature up to 70°C
Withstand 5G vibration test
High efficiency, long life and high reliability

Add to Cart Buy Now

Ships within 3 days

MEANWELL RS-25-5 Output Current 5 A Switching Power Supply

By Mean Well

₹1,887

.tg {border-collapse:collapse;border-spacing:0;}
.tg td{font-family:Arial, sans-serif;font-size:14px;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg th{font-family:Arial, sans-serif;font-size:14px;font-weight:normal;padding:10px 5px;border-style:solid;border-width:1px;overflow:hidden;word-break:normal;}
.tg .tg-e3zv{font-weight:bold}
.tg .tg-rycn{font-weight:bold;text-decoration:underline;background-color:#ffcc67;text-align:center}
.tg .tg-9hbo{font-weight:bold;vertical-align:top}
.tg .tg-yw4l{vertical-align:top}
MODEL - RS-25-5
OUTPUT
Features
Attributes
DC VOLTAGE
5V
RATED CURRENT
5A
CURRENT RANGE
0 ~ 5A
RATED POWER
25W
RIPPLE & NOISE
80mVp-p
VOLTAGE ADJ. RANGE
4.75 ~ 5.5V
VOLTAGE TOLERANCE
±2.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
INPUT
VOLTAGE RANGE
88 ~ 264VAC 125 ~ 373VDC (Withstand 300VAC surge for 5sec. Without damage)
FREQUENCY RANGE
47 ~ 63Hz
EFFICIENCY (Typ.)
86%
AC CURRENT (Typ.)
0.7A/115VAC 0.4A/230VAC
INRUSH CURRENT (Typ.)
COLD START 65A / 230VAC
LEAKAGE CURRENT
<2mA / 240VAC
AC input range selected by switch.
Protections: Short circuit / Overload / Over voltage.
Forced air cooling by built-in DC fan.
100% full load burn-in test.
Fixed switching frequency at 60KHz.
Low cost High reliability

Add to Cart Buy Now

Ships within 6 days

MEANWELL SE-600-24 Output Current 25 A Switching Power Supply

By Mean Well

₹14,159

Features:
AC input active surge current limiting AC input range selected by switch Protections:Short circuit / Overload / Over voltage / Over temperature Forced air cooling by built-in DC fan High power density 4.9w/in3 Built-in remote sense function UL approved Low cost 2 years warranty

Add to Cart Buy Now

Ships within 8 days

MEANWELL EDR-120-24 Output Current 5 A Switched Mode Power Supply

By Mean Well

₹3,185

EDR-120 is one economical slim 120W DIN rail power supply series, adapt to be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is designed 40mm in width, which allows space saving inside the cabinets. The entire series adopts the full range AC input from 90VAC to 264VAC and conforms to EN61000-3-2, the norm the European Union regulates for harmonic current.
EDR-120 is designed with metal housing that enhances the unit's power dissipation. With working efficiency up to 88.5%, the entire series can operate at the ambient temperature between -20°C and 60°C under air convection. It is equipped with constant current mode for over-load protection, fitting various inductive or capacitive applications. The complete protection functions and relevant certificates for industrial control apparatus (UL508, TUV EN60950-1, and etc.) make EDR-120 a very competitive power supply solution for industrial applications. Input Voltage: 90-264 VAC, 127-370 VDC, Output Voltage: 24 V AC Voltage: 24 ~ 28 V, Dimension: 113.5x40x125.2 mm

Add to Cart Buy Now

Ships within 10 days

Meanwell 20 W AC-DC Industrial DIN Rail Power Supply MDR-20-24

By Mean Well

₹1,887

The Meanwell 20 W AC-DC Industrial DIN Rail Power Supply MDR-20-24 is a small, lightweight power supply that's perfect for powering a variety of devices. It's got a fan to keep it cool and a variety of settings to give you control over your output. This model is designed with durability in mind. It runs on 110/220 VAC at 50/60 Hz and weighs just 0.85 lb so it's easy to carry around. This one can be mounted using optional brackets if you need to get it up high, or you can just lay it flat if you don't need the extra height. The Meanwell 20 W AC-DC Industrial DIN Rail Power Supply MDR-20-24 has an efficiency rating of 85%, which is better than most other supplies out there. This product is protected by a 3 year limited warranty, so you know that it's built to last.
This particular model can output voltages between 9 and 25 VAC at up to 20 amps, which is enough to power anything from personal computers to motors. The AC voltage can be configured to either line or mains frequency, making the unit suitable for use in countries around the world. There are several protection mechanisms built in as well, including overvoltage protection, overcurrent protection, and short circuit protection. In fact, there's even an indicator to let you know if something has gone wrong with the unit. The Meanwell MDR-20-24 also comes with a nice set of mounting hardware and includes built-in screw terminals connecting directly to wires or busbars.

Add to Cart Buy Now

Ships within 12 days

MEANWELL RS-35-5 Output Current 7 A Switched Mode Power Supply

By Mean Well

₹1,769

Output Voltage: 5 V AC Voltage: 4.5 ~ 5.5 V, Dimension: 99x82x36 mm

Add to Cart Buy Now

Ships within 30 days

Meanwell 960 W AC-DC Industrial DIN Rail Power Supply TDR-960-24

By Mean Well

₹21,323

The Meanwell 960 W AC-DC Industrial DIN Rail Power Supply TDR-960-24 is a great choice for powering your equipment. It can supply a constant 960 W of power, and the variable output voltage (13.6V to 28.8V) means that your equipment can be powered from a wide range of different power sources. The Meanwell comes with overload, overvoltage and short-circuit protection, as well as a cooling fan for keeping it running at its best temperature, so you don't have to worry about your equipment being damaged by a poorly maintained power source. It also comes with both locking and nonlocking connectors, so you can use whichever suits your specific needs.
Being rated at 960 W means it can handle the needs of most heavy-duty devices, like large digital signs or refrigeration units. It's also capable of supplying up to 125 VAC to connected devices, so it's great for use in both North American and international locations—international users will appreciate the fact that the 9VAC output is selectable between 47 - 63 Hz. The 4-pin terminal block allows easy connection to almost any device. If you're using this in a location that requires frequent power cycling or if you need to control the power via software, this unit can be set to automatically restart after a power failure (a feature many other brands don't have). This prevents your equipment from being damaged when power comes back on unexpectedly, and also helps protect against surges during brownouts/blackouts.

Add to Cart Buy Now

Ships within 30 days

MEANWELL NES-100-24 Output Current 4.5 A Switching Power Supply

By Mean Well

₹2,949

Protections: Short circuit / Overload / Over voltage.
Cooling by free air convection.
LED indicator for power on 100% full load burn-in test.
Economical non-PFC models.
Miniature size with complete protections.
Economical models with complete safety certificates
The MEANWELL NES-100-24 is a switching power supply that is designed to convert AC power into DC power. It is capable of providing a maximum output power of 100 watts and an output voltage of 24 volts DC. The power supply is designed to be highly efficient, with a typical efficiency rating of 88%.
The input voltage range of the NES-100-24 is 85-264VAC, which means it can be used in a wide range of applications across different countries. The power supply also features a built-in active PFC function, which helps to improve the power factor and reduce harmonic distortion.
The NES-100-24 is designed to be highly reliable and durable, with a mean time between failures (MTBF) of over 700,000 hours. It also features a range of protection functions, including overvoltage protection, overcurrent protection, and short circuit protection, which help to ensure the safety and longevity of the power supply.
The power supply is designed to be easy to install and use, with a compact and lightweight design that makes it suitable for a wide range of applications. It also features a range of input and output connectors, including a universal input connector, a DC output connector, and a ground terminal.
Overall, the MEANWELL NES-100-24 is a highly efficient, reliable, and versatile switching power supply that is suitable for a wide range of applications. Whether you need to power a small electronic device or a larger industrial system, the NES-100-24 is a great choice that will provide you with reliable and consistent power.

Add to Cart Buy Now

Ships within 30 days

Meanwell 240 W DIN Rail Power Supply TDR-240-24

By Mean Well

₹7,479

The Meanwell TDR-240-24 power supply is a 240 W, 85% efficient switching power supply that can provide power to a 24 V load. It's a good choice for applications that need around 496 W of power, such as small DC-DC converters or chargers. Its thin design adds to its flexibility in installation, and it uses standard mounting holes and screw sizes.
The Meanwell 240 W power supply is an excellent, high quality power supply that can be mounted on a DIN rail. The Meanwell 240 W power supply is made by the Meanwell Company, one of the most respected manufacturers of power supplies and other electronic components.
This power supply has numerous benefits. First, it's very solid and durable. It's strong enough to withstand the constant motion of trains and buses, which means it will work well in situations where you need it to be portable, such as for a school project or for a professional who needs to transport it from job site to job site. It also has 24 Volts DC output, so it's intended for use with 24 VDC systems, but it could still potentially be used with 120 VAC systems if necessary.
This product has several indicators which make it easy to use. First, there's a Power On LED indicator that lets you know when the unit is turned on or off. There's also a Power Fail LED indicator that lets you know if there are any problems with the unit during operation. Most importantly, there are two individual LEDs that let you know how much current is being drawn at any given second by the load connected to this power supply.

Add to Cart Buy Now

Ships within 30 days

MEANWELL Output Current 0.7 A Switching Power Supply, NES-15-24

By Mean Well

₹1,132

The MEANWELL NES-15-24 is a compact and reliable switching power supply designed for a variety of applications requiring a stable and efficient power source. With an output current of 0.7 A, this power supply unit is part of the NES series by MEANWELL, known for its high-quality power solutions. The NES-15-24 is particularly well-suited for applications with lower power requirements, providing a steady and regulated power output. Operating as a switching power supply, the NES-15-24 utilizes advanced technology for efficient power conversion and regulation. The 0.7 A output current makes it suitable for powering devices with lower current demands, such as small-scale electronics, LED lighting, or instrumentation. The power supply provides a 24 V output, which is a common voltage level used in many electronic applications. The compact design of the NES-15-24 allows for versatile installation in space-constrained environments, making it ideal for various industrial and electronic settings. Despite its lower output current, the NES-15-24 maintains the quality and reliability associated with MEANWELL products. The unit incorporates protective features like over-current protection and short-circuit protection to ensure the safety of connected devices. MEANWELL, renowned for its commitment to quality and innovation in power supply solutions, ensures that the NES-15-24 complies with rigorous industry standards, making it a dependable choice for applications with lower power requirements.

Add to Cart Buy Now

Ships within 30 days

MEANWELL DRT-240-24 Output Current 10 A Switching Power Supply

By Mean Well

₹11,799

Features:
Three-Phase AC 340 - 550V wide range input
High efficiency 89% and low dissipation
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
UL 508(industrial control equipment)approved
EN61000-6-2(EN50082-2) industrial immunity level
100% full load burn-in test
Fixed switching frequency at 70KHz
3 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
DRT-240-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
10A
CURRENT RANGE
0 - 10A
RATED POWER
240W
RIPPLE & NOISE (max.) Note.2
80mVp-p
VOLTAGE ADJ. RANGE
24 - 28V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±0.5%
SETUP, RISE, HOLDUP TIME
1200ms,40ms,20ms/400VAC 800ms,40ms,40ms/500VAC at full load
INPUT
VOLTAGE RANGE Note.5
Three-Phase 340-550VAC(Dual phase operation possible) 480-780VDC
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
89%
AC CURRENT (Typ.)
0.95A/400VAC 0.75A/500VAC
INRUSH CURRENT (Typ.)
COLD START 50A
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 30 days

MEANWELL Q-250D Output Current 10 A Switched Mode Power Supply

By Mean Well

₹5,781

Input Voltage: 90-264 VAC, 248-370 VDC, Output Voltage: 5 V AC Voltage: 4.75 ~ 5.5 V, Dimension: 150x140x86 mm

Add to Cart Buy Now

Ships within 30 days

Meanwell 480 W DIN Rail Power Supply with PFC Function TDR-480-24

By Mean Well

₹9,894

The Meanwell TDR-480-24 power supply is a 480 W, 85% efficient switching power supply that can provide power to a 24 V load. It's a good choice for applications that need around 496 W of power, such as small DC-DC converters or chargers. Its thin design adds to its flexibility in installation, and it uses standard mounting holes and screw sizes.
The Meanwell 480 W power supply is an excellent, high quality power supply that can be mounted on a DIN rail. The Meanwell 480 W power supply is made by the Meanwell Company, one of the most respected manufacturers of power supplies and other electronic components.
This power supply has numerous benefits. First, it's very solid and durable. It's strong enough to withstand the constant motion of trains and buses, which means it will work well in situations where you need it to be portable, such as for a school project or for a professional who needs to transport it from job site to job site. It also has 24 Volts DC output, so it's intended for use with 24 VDC systems, but it could still potentially be used with 120 VAC systems if necessary.
This product has several indicators which make it easy to use. First, there's a Power On LED indicator that lets you know when the unit is turned on or off. There's also a Power Fail LED indicator that lets you know if there are any problems with the unit during operation. Most importantly, there are two individual LEDs that let you know how much current is being drawn at any given second by the load connected to this power supply.

Add to Cart Buy Now

Ships within 30 days

MEANWELL NES-50-24 Output Current 2.2 A Switching Power Supply

By Mean Well

₹1,769

Features:
Universal AC input/Full range
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
100% full load burn-in test
2 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
NES-50-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
2.2A
CURRENT RANGE
0 - 2.2A
RATED POWER
52.8W
RIPPLE & NOISE (max.) Note.2
200mVp-p
VOLTAGE ADJ. RANGE
21.6 - 26.4V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION Note.4
±0.5%
LOAD REGULATION Note.5
±0.5%
SETUP, RISE TIME
500ms, 30ms/230VAC 1200ms, 30ms/115VAC at full load
HOLD UP TIME (Typ.)
50ms/230VAC 10ms/115VAC at full load
INPUT
VOLTAGE RANGE
85 - 264VAC 120 - 370VDC
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
86%
AC CURRENT (Typ.)
1.1A/115VAC 0.65A/230VAC
INRUSH CURRENT (Typ.)
COLD START 45A
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 30 days

MEANWELL DRP-480-24 Output Current 20 A Switching Power Supply

By Mean Well

₹23,599

Features:
Built-in passive PFC function compliance to EN61000-3-2
High efficiency 89% and low dissipation
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
UL 508(industrial control equipment)approved
EN61000-6-2(EN50082-2) industrial immunity level
100% full load burn-in test
3 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
DRP-480-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
20A
CURRENT RANGE
0 - 20A
RATED POWER
480W
RIPPLE & NOISE (max.) Note.2
120mVp-p
VOLTAGE ADJ. RANGE
24 - 28V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
SETUP, RISE TIME
1200ms, 40ms/400VAC at full load
HOLD UP TIME (Typ.)
16ms/230VAC at full load
INPUT
VOLTAGE RANGE
180 - 264VAC 250 - 370VDC
FREQUENCY RANGE
47 - 63Hz
POWER FACTOR (Typ.)
0.7
EFFICIENCY (Typ.)
89%
AC CURRENT (Typ.)
4A/230VAC
INRUSH CURRENT (Typ.)
COLD START 40A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 30 days

MEANWELL NES-150-12 Output Current 12.5 A Switching Power Supply

By Mean Well

₹4,483

AC input range selectable by switch
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
LED indicator for power on
100% full load burn-in test
High efficiency, long life and high reliability
2 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
NES-150-12
OUTPUT
DC VOLTAGE
12V
RATED CURRENT
12.5A
CURRENT RANGE
0 - 12.5A
RATED POWER
150W
RIPPLE & NOISE (max.) Note.2
120mVp-p
VOLTAGE ADJ. RANGE
11.4 - 13.5V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION Note.4
±0.5%
LOAD REGULATION Note.5
±0.5%
SETUP, RISE TIME
800ms, 20ms/230VAC 1200ms,30ms/115VAC at full load
HOLD UP TIME (Typ.)
24ms/230VAC 20ms/115VAC at full load
INPUT
VOLTAGE RANGE
90 - 132VAC/180 - 264VAC selected by switch 254 - 373VDC
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
83%
AC CURRENT (Typ.)
3A/115VAC 2A/230VAC
INRUSH CURRENT (Typ.)
COLD STAR 45A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 30 days

MEANWELL Output Current 3.2 A Industrial Power Supply, DR-75-24

By Mean Well

₹4,011   ₹4,130

You save ₹119!

2.88% OFF

The MEANWELL DR-75-24 is a robust and versatile industrial power supply known for its reliable performance and efficient power delivery. With an output current of 3.2 A, this power supply is designed to meet the demands of various industrial applications where a stable and consistent power source is crucial. Part of the DR series by MEANWELL, the DR-75-24 offers a dependable solution for powering electronic devices and systems in diverse industrial settings. Operating as an industrial power supply, the DR-75-24 is built to withstand the rigors of industrial environments. It provides a 24 V output, a standard voltage level suitable for powering a wide range of industrial electronic components and equipment. The 3.2 A output current capacity makes it suitable for applications with moderate power requirements, such as control systems, machinery, and automation equipment. The power supply unit incorporates features that enhance its reliability and longevity, including over-current protection, short-circuit protection, and over-voltage protection to safeguard connected devices from potential damage. The design also includes a rugged construction to ensure durability in challenging industrial conditions. MEANWELL, renowned for its commitment to quality and innovation in power supply solutions, ensures that the DR-75-24 adheres to stringent industry standards. In summary, the MEANWELL DR-75-24 stands as a reliable and efficient industrial power supply, providing a stable and regulated power source for various electronic applications in industrial settings.

Add to Cart Buy Now

Ships within 30 days

MEANWELL Output Current 14.6 A Switching Power Supply, NES-350-24

By Mean Well

₹4,837

The MEANWELL NES-350-24 is a highly efficient and reliable switching power supply designed for various industrial applications. With an output current of 14.6 A, this power supply unit offers a stable and consistent source of power to drive electronic devices and systems. The NES-350-24 is part of the NES series by MEANWELL, known for its high-quality power solutions. Operating as a switching power supply, the NES-350-24 employs advanced technology to convert and regulate electrical power efficiently. The 14.6 A output current capacity makes it suitable for powering devices with higher current requirements, making it versatile for use in industrial automation, LED lighting, and other electronic applications. The power supply is designed with a 24 V output, providing a standard voltage level compatible with a wide range of electronic components and systems. The unit features a robust construction to ensure durability and reliability in challenging industrial environments. Additionally, it incorporates various protection mechanisms such as over-current protection, short-circuit protection, and over-voltage protection to safeguard connected devices from potential damage. MEANWELL, recognized for its commitment to quality and innovation in power supply solutions, ensures that the NES-350-24 meets stringent industry standards. Overall, the MEANWELL NES-350-24 is a dependable and efficient power supply solution, catering to the power needs of diverse industrial applications with its high output current and reliable performance.

Add to Cart Buy Now

Ships within 30 days

MEANWELL DRP-480-24 Output Current 20 A Industrial Power Supply

By Mean Well

₹15,339

Universal AC input / Full range.
Protections: Short circuit / Overload / Over voltage / Over temperature.
Cooling by free air convection.
Can be installed on DIN rail TS-35/7.5 or 15.
LED indicator for power on 100% full load burn-in test

Add to Cart Buy Now

Ships within 30 days

MEANWELL SE-600-12 Output Current 50 A Switching Power Supply

By Mean Well

₹12,979

Features:
AC input active surge current limiting
AC input range selected by switch
Protections:Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan
High power density 4.9w/in3
Built-in remote sense function
UL approved
Low cost
2 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
SE-600-12
OUTPUT
DC VOLTAGE
12V
RATED CURRENT
50A
CURRENT RANGE
0 - 50A
RATED POWER
600W
RIPPLE & NOISE (max.) Note.2
150mVp-p
VOLTAGE ADJ. RANGE
10 - 13.5V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±0.5%
SETUP, RISE TIME
1000ms, 50ms/230VAC 1000ms, 50ms/115VAC at full load
HOLD UP TIME (Typ.)
20ms/230VAC 16ms/115VAC at full load
INPUT
VOLTAGE RANGE
90 - 132VAC / 180 - 264VAC selected by switch 254 - 370VDC
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
83%
AC CURRENT (Typ.)
12A/115VAC 7.5A/230VAC
INRUSH CURRENT (Typ.)
30A/115VAC 60A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 90 days

MEANWELL LRS-100-24 Output Current 4.5 A Switched Mode Power Supply

By Mean Well

₹1,415

LRS-100 series is a 100W single-output enclosed type power supply with 30mm of low profile design. Adopting the full range 85~264VAC input, the entire series provides an output voltage line of 3.3V, 5V, 12V, 15V, 24V, 36V and 48V.
In addition to the high efficiency up to 91%, the design of metallic mesh case enhances the heat dissipation of LRS-100 that the whole series operates from -30 °C through 70 °C under air convection without a fan. Delivering an extremely low no load power consumption (less than 0.3W), it allows the end system to easily meet the worldwide energy requirement. LRS-100 has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as TUV EN60950-1, EN60335-1,EN61558-1/-2-16, UL60950-1 and GB4943. LRS-100 series serves as a high price-to-performance power supply solution for various industrial applications.
Features:-
Universal AC input / Full range.
Withstand 300VAC surge input for 5 second
No load power consumption<0.2W
Miniature size and 1U low profile
High operating temperature up to 70°C
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Compliance to IEC/EN 60335-1(PD3) and R33100 IEC/EN61558-1, -2-16 for household appliances
Operating altitude up to 5000 meters (Note.8)
Withstand 5G vibration test
High efficiency, long life and high reliability
LED indicator for power on
Over voltage category III
100% full load burn-in test
Applications:-
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliances

Add to Cart Buy Now

Ships within 120 days

MEANWELL NES-150-24 Output Current 6.5 A Switching Power Supply

By Mean Well

₹4,601

AC input range selectable by switch
Protections: Short circuit/Overload/Over voltage
Cooling by free air convection
LED indicator for power on
100% full load burn-in test
High efficiency, long life and high reliability
2 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
NES-150-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
6.5A
CURRENT RANGE
0 - 6.5A
RATED POWER
156W
RIPPLE & NOISE (max.) Note.2
120mVp-p
VOLTAGE ADJ. RANGE
22.8 - 27.6V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION Note.4
±0.5%
LOAD REGULATION Note.5
±0.5%
SETUP, RISE TIME
800ms, 20ms/230VAC 1200ms,30ms/115VAC at full load
HOLD UP TIME (Typ.)
24ms/230VAC 20ms/115VAC at full load
INPUT
VOLTAGE RANGE
90 - 132VAC/180 - 264VAC selected by switch 254 - 373VDC
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
86%
AC CURRENT (Typ.)
3A/115VAC 2A/230VAC
INRUSH CURRENT (Typ.)
COLD STAR 45A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 90 days

MEANWELL LRS-50-12 Output Current 4.2 A Switched Mode Power Supply

By Mean Well

₹1,120

Output Voltage: 12 V AC Voltage: 13.8 ~ 16.2 V, Dimension: 99x82x30 mm

Add to Cart Buy Now

Ships within 90 days

MEANWELL LRS-150-24 Output Current 6.5 A Switched Mode Power Supply

By Mean Well

₹1,769

Features :-
AC input range selectable by switch
Withstand 300VAC surge input for 5 second
No load power consumption
Miniature size and 1U low profile
High operating temperature up to 70°C
Protections: Short circuit/Overload/Over voltage/Over temperature
Cooling by free air convection
Compliance to IEC/EN 60335-1(PD3)and IEC/EN61558-1, 2-16 for household appliances
Operating altitude up to 5000 meters
Withstand 5G vibration test
High efficiency, long life and high reliability
LED indicator for power on
100% full load burn-in test
3 years warranty
Applications :-
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliances
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
LRS-150-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
6.5A
CURRENT RANGE
0 - 6.5A
RATED POWER
156W
RIPPLE & NOISE (max.) Note.2
200mVp-p
VOLTAGE ADJ. RANGE
21.6 - 28.8V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION Note.4
±0.5%
LOAD REGULATION Note.5
±0.5%
SETUP, RISE TIME
500ms, 30ms/230VAC 500ms,30ms/115VAC at full load
HOLD UP TIME (Typ.)
40ms/230VAC 35ms/115VAC at full load
INPUT
VOLTAGE RANGE
85 - 132VAC/170 - 264VAC by switch 240 - 370VDC(switch on 230VAC)
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
89%
AC CURRENT (Typ.)
2.8A/115VAC 1.6A/230VAC
INRUSH CURRENT (Typ.)
COLD STAR 60A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 90 days

MEANWELL LRS-350-24 Output Current 14.6 A Switched Mode Power Supply

By Mean Well

₹3,775

Features:
AC input range selectable by switch
Withstand 300VAC surge input for 5 second
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan
Built-in cooling Fan ON-OFF control
IU low profile
Withstand 5G vibration test
LED indicator for power on
No load power consumption«O.75W
100% full load burn-in test
High operating temperature up to 70C
Operating altitude up to 5000 meters (Note.8)
High efficiency, long life and high reliability
3 years warranty
Applications:
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
LRS-350-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
14.6A
CURRENT RANGE
0 - 14.6A
RATED POWER
350.4W
RIPPLE & NOISE (max.) Note.2
150mVp-p
VOLTAGE ADJ. RANGE
21.6 - 28.8V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION Note.4
±0.5%
LOAD REGULATION Note.5
±0.5%
SETUP, RISE TIME
1500ms, 50ms/230VAC 1500ms,50ms/115VAC at full load
HOLD UP TIME (Typ.)
16ms/230VAC 12ms/115VAC at full load
INPUT
VOLTAGE RANGE Note.5
90 - 132VAC / 180 - 264VAC by switch 254 - 370VDC (switch on 230VAC)
FREQUENCY RANGE
47 - 63Hz
EFFICIENCY (Typ.)
88%
AC CURRENT (Typ.)
6.8A/115VAC 3.4A/230VAC
INRUSH CURRENT (Typ.)
60A/115VAC 60A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 90 days

MEANWELL LRS-50-24 Output Current 2.2 A Switched Mode Power Supply

By Mean Well

₹1,084

LRS-50 series is a 50W single-output enclosed type power supply with 30mm of low profile design. Adopting
the full range 85~264VAC input, the entire series provides an output voltage line of 3.3V, 5V, 12V, 15V,
24V, 36V and 48V.
In addition to the high efficiency up to 90%, the design of metallic mesh case enhances the heat dissipation of LRS-50 that the whole series operates from -30 °C through 70 °C under air convection without a fan. Delivering an extremely low no load power consumption (less than 0.2W), it allows the end system to easily meet the worldwide energy requirement. LRS-50 has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as TUV EN60950-1, EN60335-1,EN61558-1/-2-16, UL60950-1 and GB4943. LRS-50 series serves as a high price-to-performance power supply solution for various industrial applications.
Features:-
Universal AC input / Full range.
Withstand 300VAC surge input for 5 second
No load power consumption<0.2W
Miniature size and 1U low profile
High operating temperature up to 70°C
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Compliance to IEC/EN 60335-1(PD3) and R33100 IEC/EN61558-1, -2-16 for household appliances
Operating altitude up to 5000 meters (Note.8)
Withstand 5G vibration test
High efficiency, long life and high reliability
LED indicator for power on
Over voltage category III
100% full load burn-in test
Applications:-
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Household appliances

Add to Cart Buy Now

Ships within 90 days

MEANWELL DRP-240-24 Output Current 10 A Industrial Power Supply

By Mean Well

₹8,967

Features:
Universal AC input / Full range
Built in active PFC function
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
UL 508(industrial control equipment)approved
LED indicator for power on
100% full load burn-in test
Fixed switching frequency at 100KHz
3 years warranty
table, th, td {
border: 1px solid black;
border-collapse: collapse;
}
th, td {
padding: 5px;
text-align: center;
}
Model
DRP-240-24
OUTPUT
DC VOLTAGE
24V
RATED CURRENT
10A
CURRENT RANGE
0 - 10A
RATED POWER
240W
RIPPLE & NOISE (max.) Note.2
80mVp-p
VOLTAGE ADJ. RANGE
24 - 28V
VOLTAGE TOLERANCE Note.3
±1.0%
LINE REGULATION
±0.5%
LOAD REGULATION
±1.0%
SETUP, RISE TIME
800ms, 40ms/230VAC 800ms, 40ms/115VAC at full load
HOLD UP TIME (Typ.)
24ms/230VAC 24ms/115VAC at full load
INPUT
VOLTAGE RANGE Note.5
85 - 264VAC 120 - 370VDC
FREQUENCY RANGE
47 - 63Hz
POWER FACTOR (Typ.)
0.96/230VAC 0.99/115VAC at full load
EFFICIENCY (Typ.)
84%
AC CURRENT (Typ.)
2.8A/115VAC 1.4A/230VAC
INRUSH CURRENT (Typ.)
COLD START 27A/115VAC 45A/230VAC
LEAKAGE CURRENT

Add to Cart Buy Now

Ships within 90 days

MEANWELL LRS-100-12 Output Current 8.5 A Switched Mode Power Supply

By Mean Well

₹1,415

Output Voltage: 12 V AC Voltage: 10.2 ~ 13.8 V, Dimension: 129x97x30 mm

Add to Cart Buy Now

Previous Next

Page 1 of 1 results
