| Lens | 3.6 mm Lens |
| Type of Product | Bullet Camera |
| Resolution | 2MP (1920 × 1080), 960H (960 × 576/ 960 × 480) |
| Model No | CP-UMC-TA24L3-L |
Lens |
3.6 mm Lens |
Type of Product |
Bullet Camera |
Resolution |
2MP (1920 × 1080), 960H (960 × 576/ 960 × 480) |
Model No |
CP-UMC-TA24L3-L |
Power Consumption |
Max 6.6 W (12 VDC, IR on) |
Lens Type |
Fixed-focal |
Dimension |
161.6 mm × 69.7 mm × 70.0 mm (L × W × H) |
Operating Temperature |
–30 °C to +60 °C (–40 °F to +140 °F) |
Image Sensor |
1/3” CMOS Image Sensor |
Minimum Illumination |
0.01 lux@F2.0 (Color, 30 IRE), 0.01 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on) |
Lens Mount |
M12 |
Power Supply |
12 VDC |
Shutter Speed |
PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s |
Effective Pixels |
1920 (H) × 1080 (V) |
IR Range |
30 m |
Aperture |
F2.0 Max. |
Operating Humidity |
<95% (RH), non-condensing |
Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° |
Audio |
Built-in Mic, up to 8 Mtr. |
Frame Rate |
CVI: PAL: 1080p@25 fps, NTSC: 1080p@30 fps; AHD: PAL: 1080p@25 fps, NTSC: 1080p@30 fps; TVI: PAL: 1080p@25 fps, NTSC: 1080p@30 fps; CVBS: PAL: 960H, NTSC: 960H |
Gain control |
Auto, Manual (AGC) |
Close Focus Distance |
3.6 mm: 0.7 m; 2.8 mm: 0.5 m |
Viewing Angle |
3.6 mm: H: 89°, V: 48.2°, D: 109.1°; 2.8 mm: H: 111.3°, V: 60.8°, D: 134.2° |
IR Control Type |
Auto, Manual |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Adtiya Infotech Ltd |
Storage Humidity |
<95% (RH), non-condensing |
Casing Material |
Plastic |
