| Lens | 8.0 mm |
| Type of Product | Network CCTV Camera |
| Model No | SS-NC50L5CP-YXF-M8(4K) |
| IP Rating | IP67 |
Lens |
8.0 mm |
Type of Product |
Network CCTV Camera |
Model No |
SS-NC50L5CP-YXF-M8(4K) |
IP Rating |
IP67 |
IR Distance |
50 m |
Power Consumption |
≤8.0 W |
Weight |
≤1.0 Kg (No HDD) |
Lens Type |
Board Lens |
Dimension |
180 mm x 70 mm x 70 mm |
Color |
White & Black |
Image Sensor |
1/2.7 inch (9.41 mm) Progressive Scan CMOS |
Minimum Illumination |
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
Lens Mount |
6.0 mm / 8.0 mm / 12.0 mm |
Power Supply |
DC 12 V/2A input, PoE (IEEE802.3af)(Class 0) |
Shutter Speed |
1/50 s to 1/10, 000 s |
Camera |
8.0 MP |
Warranty Duration |
2 Year |
Series |
Advanced Analytics |
Network Protocol |
HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP, FTP, DHCP |
Material |
Aluminum + ABS |
Audio Compression |
G.711, Support bidirectional talk, Audio & Video synchronization |
Features |
Human Detection, Face Detection, People Counting, Customer Flow Statistics |
WDR |
≥120 db |
Certification |
CE, FCC, RoHS |
Day/Night Mode |
Auto (ICR) / Color / Black & White |
Video Bit Rate |
128 KBPS to 8 MBPS |
Digital Zoom |
16X |
Audio Input |
Yes, 1 Ch, 2 Vp-p 1 kᲲ Impedance (Optional) |
Audio Output |
Yes, 1 Ch, 16 Ჲ Impedance (Optional) |
IR LED |
18 SMD IR LED |
Video Streaming |
Main Stream : 3840 x 2160, @15 FPS, 2880 x 1616@25 FPS, 2560 x 1440, @25 FPS, 1920 x 1080, 25 FPS Sub Stream 1 : 800 x 448, @25 FPS |
Operation Temperature |
-10°C to + 65°C |
Country of Origin |
India |
Network Interface |
1*RJ45 Connector 10/100 MBPS |
Name of Manufacturer/Packer/Importer |
Securus South India Coordinator |
Video Encoding |
H.265AI/H.265+/H.265/H.264+/H.264 |
Image Settings |
Mirror Image/Reverse/Color Settings |
Shutter Type |
Manual/Auto |
Image Size |
3840 x 2160 (8.0 MP), 2880 x 1616 (5.0 MP), 2560 x 1440 (4.0 MP), 2304 x 1296 (3.0MP), 1920 x 1080 (2.0 MP) |
Operation humidity |
0% to 90% |
Monitoring |
Mobile: RMEye Pro (iOS & Android) |
