| Tone | When inserting the short circuit bar in direction A: Intermittent sound (high-pitched) beep, beep, beep, beep When inserting the short circuit bar in direction B (when removing the short circuit bar): Intermittent sound (high-pitched) beep, beep |
| Type | Standard Volume Type |
| Protection Class | Ip40 |
| Sound Pressure | Distance 0.1m, Rated voltage: Typ. 80 dB (horn) or more |
Tone |
When inserting the short circuit bar in direction A: Intermittent sound (high-pitched) beep, beep, beep, beep When inserting the short circuit bar in direction B (when removing the short circuit bar): Intermittent sound (high-pitched) beep, beep |
Type |
Standard Volume Type |
Protection Class |
Ip40 |
Sound Pressure |
Distance 0.1m, Rated voltage: Typ. 80 dB (horn) or more |
Series |
B2BJ Series |
Storage Temperature |
-25 To 65 ℃ (No Freezing Or Condensation) |
Type of Product |
Buzzer |
Model No |
M2BJ-B06C |
Country of Origin |
Japan |
Shape |
Rectangle |
Durability |
1000h or more |
Buzzer Sound |
When shorting piece A is inserted: Intermittent sound (pi / pi / pi / pi), shorting piece B direction is inserted (when shorting piece is removed): Continuous sound (pi / pi) |
Applicable Voltage (V) |
AC/DC 6 |
Monotaro ID |
46483701 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-10 to 55 (no freezing or condensation) |
Withstand voltage (V / min) |
AC 1000 (between each terminal and earth) |
Inrush current (A) |
Up to 1 |
Sound Pressure Level (dB) |
TYP.80 (horn) or more (distance 0.1m, rated voltage) |
Mass (g) |
About 9 |
Insulation Resistance (MOhm) |
100 or more (between each terminal and ground) |
Current Consumption (mA) |
DC max 20, AC max 20 |
Frequency (kHz) |
(Drive) 4 ± 0.5 |
Operating Ambient Humidity |
35 to 85% RH |
Body Shape |
Round Body |
